| 类型 | 圆柱三线接近传感器M12埋入式 | 圆柱三线接近传感器M12非埋入式 | |||||
| 外观 |
|
|
|||||
| 型号 | NPN常开 | PI-02M12NO（常用推荐） | PI-04M12NO | PI-06M12NO | PI-04M12NOH
（常用推荐） |
PI-08M12NOH | PI-10M12NOH |
| NPN常闭 | PI-02M12NC | PI-04M12NC | PI-06M12NC | PI-04M12NCH | PI-08M12NCH | PI-10M12NCH | |
| PNP常开 | PI-02M12PO | PI-04M12PO | PI-06M12PO | PI-04M12POH | PI-08M12POH | PI-10M12POH | |
| PNP常闭 | PI-02M12PC | PI-04M12PC | PI-06M12PC | PI-04M12PCH | PI-08M12PCH | PI-10M12PCH | |
| 感应距离(mm) | 2mm | 4mm | 6mm | 4mm | 8mm | 10mm | |
| 开关频率(KHz) | 2KHz | 1KHz | 0.4KHz | 1KHz | 0.5KHz | 0.3KHz | |
| 响应时间 | 0.1ms | 0.2ms | 0.5ms | 0.2ms | 0.5ms | 1ms | |
| 重复精度 | <3% | ||||||
| LED指示灯 | 有 | ||||||
| 磁滞 | <15%(sr) | ||||||
| 工作电压 | 10～30 VDC | ||||||
| 无负载电流 | <10mA | ||||||
| 最大负载电流 | 150mA | ||||||
| 过载保护点 | 180mA | ||||||
| 短路保护 | 有 | ||||||
| 漏电流 | <0.01mA | ||||||
| 电压降 | <1.5V | ||||||
| 保护等级 | IP67 | ||||||
| 工作环境温度 | -25℃～70℃ | ||||||
| 温度飘移 | <10% | ||||||
| 外壳材质 | 铜镀镍 | ||||||
| 感应面材质 | PBT | ||||||
| 电线 | 长度2米，直径4mm | ||||||
PI-02M12NO；PI-02M12NC；PI-04M12NO；PI-04M12NC；PI-06M12NO；PI-06M12NC；PI-04M12NOH；PI-04M12NCH；PI-08M12NOH；PI-08M12NCH；PI-10M12NOH；PI-10M12NCH
PI-02M12PO；PI-02M12PC；PI-04M12PO；PI-04M12PC；PI-06M12PO；PI-06M12PC；PI-04M12POH；PI-04M12PCH；PI-08M12POH；PI-08M12PCH；PI-10M12POH；PI-10M12PCH
PI-02M12NO；PI-02M12NC；PI-04M12NO；PI-04M12NC；PI-06M12NO；PI-06M12NC；PI-02M12PO；PI-02M12PC；PI-04M12PO；PI-04M12PC；PI-06M12PO；PI-06M12PC
PI-04M12NOH；PI-04M12NCH；PI-08M12NOH；PI-08M12NCH；PI-10M12NOH；PI-10M12NCH；PI-04M12POH；PI-04M12PCH；PI-08M12POH；PI-08M12PCH；PI-10M12POH；PI-10M12PCH
